Three Major Operation Steps for Starting the Automatic Winding Machine

1. Before using the automatic winding machine, confirm the power supply:

The voltage of the automatic winding machine developed by our company is AC220v±10% in one direction. Confirm that the voltage is within the above range. If the range of the automatic winding machine is unstable, it is likely to cause voltage damage to the automatic winding machine.

2. Before using the automatic winding machine, confirm the air pressure:

The air pressure required by this equipment is within the range of 0.5mpa±0.1mpa. Before using the automatic winding machine, please adjust the air pressure to the above range. When the air pressure is too low, turn off the power of the automatic winding machine to make it The device is at a standstill. After the above two operations, turn on the green power switch on the right side of the automatic winding machine.

3. Before using the automatic winding machine, reset it:

① Before using the automatic winding machine, the main air source must be turned on, and the equipment must return to the origin.

②Press the reset button to restore the automatic winding machine to the original position, that is, the reset is completed, and the reset light is on.

③When the homing of the origin of the automatic winding machine does not meet the requirements, the device will alarm and display the content of the alarm. You can refer to the 1/0 table to effectively release the alarm content.
